R.P

5KW

BAT.V

48V(D.C)

R.V

34V(A.C)

R.C

113A

R.P.M

2850

Frequency

0-200Hz

Rating

60min

Protection Lv.

IP54

Encode Signal

64P/rev

Application

6-8 Seats Tour-Bus

Structure Features

( Shaft Extension & Connection)

Square Flange Connection, Internal Spline(m=1,z=18),

                  With Temp. & SPD.Sensor
